The GV-Hot Swap NVR System V5 features a powerful data storage capacity. It comes with a selection of 4U (20 -bay) or 3U (16 / 8-bay) and hot-swappable SATA mobile racks. Depending on HDD size, the GV-Hot Swap NVR System V5 can store up to 200 terabytes of recorded data. Support for hot-swapping makes data storage and management more convenient.
GeoVision Surveillance System empowers the GV-Hot Swap NVR System V5 with a maximum of 32 audio and video channels. Its networking capability makes remote access and control of the system possible. Additionally, its compatibility with other GeoVision accessories can cater to any kind of needs or budgets. By extending the compatibility to the third-party IP devices (license required), GV-NVR provides a pure IP solution to GV-Hot Swap NVR System V5.
Các tính năng chính:
Powered by Intel Core i7 Processor
64-bit Windows 10 IoT Enterprise
Support H.265 CPU and GPU decoding
Support 32-channel GV-NVR (pure IP surveillance)
Maximum storage capacity up to 200 TB (4U 20-Bay) / 160 TB (3U 16-Bay) / 80 TB (3U 8-Bay)
Hot-swap status LED panel
Dual Gigabit LAN ports
4U (20-bay) or 3U (16 / 8-bay) hot-swap SATA HDDs for data storage
Built-in 4 inputs and 4 outputs
Extreme performance for GV-NVR operation
Pre-installed SSD for recovery
Supported RAID type:0,1,3,5,6,10,00,30,50,60,100 Single Disk or JBOD (optional)
Redundant power supply (optional)
Compatible with full selections of GeoVision accessories
Anti-vibration feature to provide the disk throughput of 95% or higher
CE, FCC, LVD compliant
|Số model||Tên gọi||Chi tiết|
|GV-IO 12-In Card||With 12-point digital inputs, this card can expand the GV-Hot Swap DVR/NVR V5 up to 16 sensor inputs.|
|GV-IO 12-Out Card||With 12-point relay outputs, this card can expand the GV-Hot Swap DVR/NVR V5 up to 16 alarm outputs.|
|GV-Data Capture V3 Box||GV-Data Capture V3 Box can integrate the GV-Hot Swap DVR / NVR / VMS to an electronic POS system, while GV-Data Capture V3E Box can establish such integration through LAN or Internet.|
|GV-COM V3||This unit can add 1 RS-485 port to your computer through a USB connector.|
|GV-IO Box Series||GV-IO Box series (4E / 4 Ports / 8 Ports / 16 Ports) provide 4 / 8 / 16 inputs and relay outputs and support both DC and AC output voltages, with optional support for Ethernet module and 4E additionally supporting PoE, TCP/IP and RS-485 connection.|
|GV-Joystick V2||GV-Joystick V2 facilitates the PTZ camera control. It can be either plugged into the GV-Hot Swap DVR/NVR V5 for independent use or connected to GV-Keyboard to empower the operation.|
|GV-Keyboard V3||The GV-Keyboard V3 is designed to program and operate GV-System and GV-VMS, and it can also be connected with PTZ cameras directly for PTZ control.|
|GV-IR Remote Control||The GV-IR Remote Control provides easy control of the GV-Hot Swap DVR / NVR / VMS System.|
|Gigabit Network Card||The Gigabit Network Card can support a single gigabit port. The number of gigabit ports supported varies based on models and combination of optional cards. Up to 3 gigabit ports can be supported.|
|RAID Card||The supported RAID types include 0,1,3,5,6,10,00,30,50,60,100 Single Disk or JBOD.|
|Redundant Power Supply||The Redundant Power Supply comes with 2 hot-swap modules for 3U models and for 4U models. When 1 module is down, the other module can still supply full power to the system.
– 3U 8 Bays models: 460W 1+1 mode; 100~240V, 47~63HZ
– 3U 16 Bays models: 550W 1+1 mode; 100~240V, 47~63HZ
– 4U 20 Bays models: 800W 1+1 modes; 90~264V, 47~63HZ
Specifications are subject to change without notice.
The disk throughput test was conducted by a 3rd-party HDD manufacturer. The level of vibration produced by the system’s hard drive operation and fan energy is minimized to have an effect of less than 5% on the disk throughput when using 8 TB hard drives.
